Signature Packaged Air Conditioner
14 SEER 4 Ton Louvered Packaged Air Conditioner
- Approved for installation in manufactured housing and mobile homes
- Multi-Positional Application
- Environmentally friendly R-410A refrigerant
- Insulated to minimize heat loss and reduce sound
- Efficient multispeed motor for wide airflow range
- Low ambient kits available
- Utility connections on right side
- One piece base design for strength and stability
- Rounded corners for safety and an attractive, clean appearance
- Available in 2, 2.5, 3, 3.5, 4, and 5 TON capacities
- All units ETL and ETLC approved and AHRI Certified
- One piece no leak top design
| SEER | 14 |
| SEER2 | 13.4 |
| EER | 11 |
| EER2 | 10.6 |
| CFM | 1600 |
| TONNAGE | 4 |
| COOLING CAPACITY (BTU) | 45500 |
| VOLTAGE (V) | 208-230 |
| PHASE | 1 |
| CYCLE | 60 |
| MAX FUSE BREAKER (A) | 45 |
| MIN CIRCUIT AMPACITY (A) | 28.7 |
| COLOR | Gray |
| COLOR FAMILY | Gray |
| RATED LOAD | 16.9 |
| MAX COVERAGE AREA | 2000 |
| REFRIGERANT TYPE | R-410A |
| REFRIGERANT VOLUME (OZ) | 115 |
| DECIBEL RATING (DBA) | 77 |
| MIN AMBIENT HEAT (F) | 0 |
| COMPRESSOR MOTOR TYPE | Single Stage |
| CONDENSER FAN MOTOR TYPE | ECM |
| CONDENSER FAN MOTOR HP | 1/4 |
| BLOWER MOTOR TYPE | ECM |
| BLOWER MOTOR HP | 3/4 |
| BLOWER MOTOR SPEEDS | Multi-speed |
| BLOWER MOTOR RPM | 850-1640 |
| FILTER TYPE | Replacable |
| FILTER SIZE | 20×20 |
| METERING DEVICE | TXV |
| AUXILIARY HEATER INCLUDED | No |
| AUXILIARY HEATER AVAILABLE | Yes |
| AUXILIARY HEATER SIZES | 5kw, 7.5kw, 10kw, 15kw, 20kw |
| UL RECOGNIZED | No |
| UL LISTED | No |
| ETL LISTED | Yes |
| ETL CERTIFIED | No |
| LEED CERTIFIED | No |
| ASHRAE COMPLIANT | No |
| ENERGY STAR COMPLIANT | No |
| ENERGY STAR CERTIFIED | No |
| AHRI CERTIFIED | Yes |
| REGISTERED WARRANTY | 10-Year Parts Limited Warranty |
| BASE WARRANTY | 5 year base limited parts warranty |
| HAS BATTERIES | No |
| CONTAINS ELECTRONICS | Yes |
| CONTAINS CHEMICALS | Yes |
| CONTAINS AEROSOL | Yes |
| CONTAINS COMPRESSED GAS | Yes |
| PROPOSITION 65 WARNING | Yes |
| RESTRICTED STATES | No |
| NET DEPTH (IN) | 47.66 |
| NET HEIGHT (IN) | 44.89 |
| NET WIDTH (IN) | 56.13 |
| NET WEIGHT (LBS) | 411.00 |
| GROSS DEPTH (IN) | 48.00 |
| GROSS HEIGHT (IN) | 46.00 |
| GROSS WIDTH (IN) | 57.50 |
| GROSS WEIGHT (LBS) | 461 |
| FREIGHT CLASS | 125 |
